2' x 3' CNC Router

Click a Picture to Zoom

Fla100 00 120130323 85668 i0h7ia
Fla10020130323 85668 6ayko9

2' x 3' CNC Router

Product Code:
920 000
Availability:
In Stock

Product Rating:
1 review

$1,599.00

$1,399.00

Options

Stock Availability

These kits are available for immediate shipment.  If the website says in stock, it will ship by the next business day garuanteed!

What’s Included

The base kit comes in the following subsystems:

  • Table Assembly (FLA110-00)
  • Gantry Assembly (FLA120-00)
  • Z-Axis Gantry Assembly (FLA130-00)
  • Z-Axis Assembly (FLA140-00)

The kit includes:

  • Aluminum Extrusion, drilled and tapped for easy assembly
  • Pre-Drilled cold rolled steel rails for X, Y, and Z
  • Linear Motion Components
  • Drive components (screws, bearing blocks, couplers, etc.)
  • All required fasteners

The base kits come with all of the pieces that you need for the mechanical assembly. Once you are done with the assembly you will just need to hook your electronics to it and off you go. We even provide mounting screws for the electronics.

What's Not Included

  • Electronics options - This includes motors, cables, drives, power supply, limit switches, relays, etc. Check out our Nema 23 or Nema 34 electronics kits for some great options that have been tested and optimized to work with this machine.
  • Cutting spindle or router, and corresponding spindle or router mount.
  • Spoilboard or other workholding
  • PC
  • Mach3 CNC Control Software, CAM Software, or CAD software
  • Cable management. We now offer Cable Track!
  • Dust collection.
  • Workbench to mount machine on

Plans

Fine Line Automation has a new set of plans for our 2'x3' machine (FLA100). The actual working area is 23.75" x 35.75". The plans below are for the NEMA 23 version of the kit.  If you want to build the NEMA 34 version of the kit, all of the aspects of the design are the same except for the motor shaft couplers and the motor mount plate.

NEW 2013-Q2 PLANS - We have redone the plans for the FLA100.  The latest plans are now availabe in EASM format, pdf, and Solidworks 2012. If you do not have Solidworks, we suggest viewing the files in the EASM by downloading the  free edrawings viewer. If you have any questions or issues with the plans, please

DOWNLOAD

Assembly Videos

We are working to get assembly videos for the complete kit up here on the site. Right now, we only have portions of the kit. Keep checking back as new videos will be posted shortly.

Property Value
X Axis Travel 35.75 inches
Y Axis (Gantry) Travel 23.75 inches
Z Axis (Vertical) Travel 5.25 inches
X Axis Drive System 5 Start ACME Leadscrew
Y Axis Drive System 5 Start ACME Leadscrew
Z Axis Drive System 5 Start ACME Leadscrew
Repeatability Up To 0.002"
Accuracy Up To 0.005"
Rapids - NEMA 23 Up To 200 IPM+
Feedrates - NEMA 23 Up To 150 IPM+
Rapids - NEMA 34 Up To 250 IPM+
Feedrates - NEMA 34 Up To 200 IPM+

(1 customer review)

Write your own review

 Great product, and support!
Submitted on  By

Unbeatable quality for an unbeatable price that others charge for a smaller wooden machine! Owner stands 100% behind the product and it's customers, even if you pick up the machine second-hand. Now that's something.
